7-inch HD Wireless Vehicle Monitoring System

7-inch HD Wireless Vehicle Monitoring System

HDW125Q, HDW897

STONKAM 7-inch high-definition wireless vehicle monitoring system is easy to install.The monitor has the touch screen function, and the camera base is a magnet, so the installation is simple and convenient. The open transmission distance is as far as 984ft, and the signal is stable and anti-interference. This system is suitable for forklifts, cranes, trailers, farming machines, RVs, semi-trailers, vans and other vehicles.

Anfrage

STONKAM® bedient ausschließlich Unternehmen. Bitte stellen Sie sicher, dass die E-Mail-Adresse des Unternehmens sowie die Angaben zum Land/der Region korrekt sind. Wir werden Ihnen so schnell wie möglich antworten!

Merkmale

【1080P HD wireless vehicle monitoring camera】 With 1080P CMOS imageacquisition sensor, you can clearly view the situation around the vehicle. The device also has night vision function, which provides you with a clear vision for 24 hours.

【Touch screen optional】 The operation is more convenient, simple and quick, more durable and smoother, and the service life is prolonged.

【Easy installation】 With magnet base, STONKAM HD Wireless Camera can be installed without drilling. The range of available vehicles is wide and the flexibility is high.

【Transmission distance up to 984ft】 The open transmission distance is as far as 984ft, and the signal is stable and anti-jamming. Even in high-speed or long-distance operation, the monitor will display the surrounding environment in real time, making your driving or operation more convenient without interference, flicker, blur or delay.

【Automatic pair】 Manual and automatic pair are supported, and the setting is quick and simple. After pairing, you only need to connect the power supply in the vehicle to work.

【12 hours of battery life】 The rechargeable camera with battery has up to 12 hours battery life in the daytime, suitable for outdoor usa and long-time operation.

【Waterproof】The wireless vehicle monitoring monitor adopts IP66 waterproof shell, and the antenna is built in, which is beautiful and durable. The wireless monitoring camera on the vehicle is waterproof IP69K, no matter whether it is rainy, snowy or foggy, the camera will not be affected.

【4-channel monitoring system】 A variety of monitors modes, quad view, double view and single view to meet various monitoring needs and reduce blind spots

【Reverse cursor】The reverse cursor can be adjusted in any position and can be used for parking and reversing without relying on the rear view mirror alone.

Wireless vehicle monitor:

LCD Dimension	7"
Resolution	1024x 3 (RGB) x600
Contrast	700:1
Brightness	650cd/m²
Viewing Angle	U:85 / D:85, R/L:85
Aspect Ratio	16:9
Channel	4 channels
Operating Frequency	2408MHz ~ 2478MHz(ISM band)
Receiving Sensitivity	-78dBm
Transmission Power	FCC≤26dBm CE≤20dBm MIC≤10dBm
Decompression Form	H.264
Modulation	FHSS
Delay	130ms
Transmission Distance	FCC≤300 M CE≤200 M MIC≤60 M
System Format	PAL / NTSC
Power Supply	DC 10-32V
Power Consumption	Max.10W
Loudspeaker	1.5W/8Ω
Operating Temp. & Humidity	-20~+70ºC,RH90%MAX
Storage Temp. & Humidity	-30~+80ºC,RH90%MAX

Wireless vehicle monitoring camera:

Battery Capacity	3.6V/6400mAh
Charging Voltage	5V-12V
Charging Time	5V/8H，12V/3H
Charging Current	5V/1.5A(MAX)，12V/1.5A(MAX)
Discharging Time	12H（daytime） 5H（night）
Charging Temperature	0~+40℃
Discharging Temperature	-20~+60℃
Storage Temperature	-20~+60℃
Waterproof Rating	IP69K
Dimension	116 x 80 x 66（mm）
Weight	670g
Sensor	1/2.9” CMOS SENSOR
Effective Pixels	1920 x 1080 pixels
AGC	Auto
Signal to Noise Ratio	38dB
White Balance	Auto
BLC	Auto
Operation Frequency	2403-2478MHZ
Transmission Distance (barrier free)	300m(20dBm)
Receiving sensitivity	-78dBm
Video Decode	H.264
Transmission power	10dBm/20dBm
Modulation	FHSS
Delay	170ms
RF Bit Rate	12Mbps
Minimum Illumination	0Lux
Night Vision Distance	8-10m
Audio	Optional
Viewing Angle	130°
IR-cut function	Optional

What are the benefits of STONKAM® 7-inch HD Wireless Vehicle Monitoring System?

1080P HD wireless vehicle monitoring camera

With 1080P CMOS imageacquisition sensor, you can clearly view the situation around the vehicle. The device also has night vision function, which provides you with a clear vision for 24 hours.

Touch screen optional and easy operation

Touch screen optional

With magnetic base, no drilling, no wiring, easy installation!

With magnet base, STONKAM HD Wireless Camera can be installed without drilling. The range of available vehicles is wide and the flexibility is high.

STONKAM HD Wireless Camera

Open transmission distance up to 984ft

Even in high-speed or long-distance operation, the monitor will display the surrounding environment in real time, making your driving or operation more convenient without interference, flicker, blur or delay.

Wireless vehicle monitor

Strong anti-interference, Stable connection

Operating frequency: 2408MHz ~ 2478MHz

STONKAM® wireless camera system adopts the FHSS technology to guarantee the privacy and anti-interference of connection.

STONKAM® wireless camera system

Easy Installation + Instant Pairing = Save more money and efficiency

After being paired for the first time, the wireless monitor and wireless camera start to function simply by connecting them to power supply of the vehicle.

wireless monitor and wireless camera

With rechargeable battery, it has up to 12 hours battery life, and has ultra-low standby power consumption

The rechargeable wireless vehicle camera with battery has up to 12 hours battery life in the daytime, and can automatically stand by and wake up the monitor. When the standby power consumption is less than 0.01W, and it can save power without manual shutdown when not in use.

Built-in antenna and waterproof shell, beautiful and durable

The wireless vehicle monitoring monitor adopts IP66 waterproof shell, and the antenna is built in, which is beautiful and durable. The wireless monitoring camera on the vehicle is waterproof IP69K, no matter whether it is rainy, snowy or foggy, the camera will not be affected.

Support multiple display modes, such as quad-view mode, split-view mode, single view mode.

The channels for the quad-view and split-view can be set flexibly.

Wireless vehicle monitoring kit

Correct color deviation during the day and protect driving safety at night

STONKAM 1080P Vehicle Wireless Rechargeable Camera can support IR-CUT, thoroughly solving the problem of color deviation of green plants under sunlight and ensuring clear recording; And the night vision distance is up to 10 meters, ensuring safe driving!

1080P Vehicle Wireless Rechargeable Camera

Wireless vehicle monitor

Multiple Application Scenarios

With top grade high quality, STONKAM® HD Digital Wireless Vehicle Monitor System can be applied to various vehicles, such as forklift, crane, harvester, etc.


Harvester	Excavator

Farm	Forklift

Crane	Planter

Applications

STONKAM 7-inch vehicle wireless monitor can be applied to all kinds of vehicles through simple installation without wiring, and combined with high-definition vehicle wireless camera to form a perfect 7-inch high-definition wireless vehicle monitoring system.

For Truck:

For Harvester:

Digital Wireless Vehicle Monitor System

For Planter:

Wireless Vehicle Monitor System
