7 inch HD Digital Wireless Monitor

HDW121Q

STONKAM® 7 inch HD Digital Wireless Monitor is easy to install. It supports quad view and auto pairing; good for truck, trailer, RV, etc. It can work with HD wireless cameras to form excellent Wireless Vehicle Monitor System. Click to see more STONKAM® Wireless Monitor System products.

Anfrage

STONKAM® bedient ausschließlich Unternehmen. Bitte stellen Sie sicher, dass die E-Mail-Adresse des Unternehmens sowie die Angaben zum Land/der Region korrekt sind. Wir werden Ihnen so schnell wie möglich antworten!

Typnr. Stellen Sie sich vor* Nachricht *

Merkmale

  • Support 4CH wireless camera and wireless transmitter.

  • Support multiple display modes, such as quad-view mode, split-view mode, single view mode, and the channels for the quad-view and split-view can be set flexibly.

  • Supports both manual and automatic pairing.

  • Supporting 1080P/720P camera input.

  • Touch screen optional.

  • Support 5 trigger input-wires, includes 4 channel single view trigger display and 1 channel split view trigger display, and the split view image can be set flexibly. In addition, the trigger for time to return the main display and triggering priority of 5 trigger input-wires can be configurable.

  • Auto-dim lighting control; screen brightness decreases automatically after the environment gets dark for 3 seconds.

  • Auto scan function available, each channel can turn on or off auto scan function and adjust the scan time from 5 to 60 seconds.

  • Rear view parking lines can be configured.

LCD Dimension

7"

Resolution

1024x 3 (RGB) x600

Contrast

700:1

Brightness

600cd/m²

Viewing Angle

U:80 / D:85, R/L:85

Aspect Ratio

16:9

Channel

4 CH

Operating Frequency

2400MHz ~ 2483.5MHz(ISM band)

Receiving Sensitivity

-78dBm

Transmission Power

FCC≤26dBm

CE≤20dBm

MIC≤10dBm

Decompression Form

H.264

Modulation

FHSS

Delay

200ms

Transmission Distance

FCC≤300 M

CE≤200 M

MIC≤60 M

System Format

PAL / NTSC

Power Supply

DC 10-32V

Power Consumption

Max.10 W

Loudspeaker

1W/8Ω

Operating Temp. & Humidity

-20~+70ºC,RH90%MAX

Storage Temp. & Humidity

-30~+80ºC,RH90%MAX





What are the benefits of STONKAM® 7 inch Digital Wireless Vehicle Monitor?



7 inch Digital Wireless Vehicle Monitor




Easy Installation + Instant Pairing = Save more money and efficiency

After being paired for the first time, the wireless monitor and wireless camera start to function simply by connecting them to power supply of the vehicle.

7 inch Digital Wireless Vehicle Monitor





Strong anti-interference, Stable connection

Operating frequency: 2400MHz ~ 2483.5MHz

STONKAM® wireless camera system adopts the FHSS technology to guarantee the privacy and anti-interference of connection.

2.4GHz Digital Wireless Camera System





Open transmission distance up to 984ft (300m)

2.4GHz Digital Wireless Camera System




Support multiple display modes, such as quad-view mode, split-view mode, single view mode.

The channels for the quad-view and split-view can be set flexibly.

Digital Wireless Camera System





Touch screen optional

Digital Wireless Camera System




Multiple Application Scenarios

With top grade high quality, STONKAM® HD Digital Wireless Vehicle Monitor can be applied to various vehicles, such as forklift, crane, harvester, etc.

Wireless vehicle Monitor

Harvester

Excavator

Wireless vehicle Monitor

Farm

Forklift
Wireless vehicle Monitor,

Crane

Planter





Applications

STONKAM® Digital Wireless Vehicle Monitor can be applied to various vehicles by easy installation without running long cables.

Digital Wireless Vehicle Monitor for truck

Digital Wireless Vehicle Monitor for harvester

Digital Wireless Vehicle Monitor for planter
