7 Inch HD Digital Wireless Monitoring System

7 Inch HD Digital Wireless Monitoring System

HDW125Q, HDW871

STONKAM® Waterproof 7 inch HD digital wireless rear view camera system is easy to install. It supports quad view, good for truck, trailer, RV, etc.

Anfrage

STONKAM® bedient ausschließlich Unternehmen. Bitte stellen Sie sicher, dass die E-Mail-Adresse des Unternehmens sowie die Angaben zum Land/der Region korrekt sind. Wir werden Ihnen so schnell wie möglich antworten!

Merkmale

Support 4CH wireless camera and wireless transmitter.
Waterproof; with built-in antenna.
Support multiple display modes, such as quad-view mode, split-view mode, single view mode, and the channels for the quad-view and split-view can be set flexibly.
Supports both manual and automatic pairing.
Supporting 1080P/720P camera input.
Touch screen optional.
Support 5 trigger input-wires, includes 4 channel single view trigger display and 1 channel split view trigger display, and the split view image can be set flexibly. In addition, the trigger for time to return the main display and triggering priority of 5 trigger input-wires can be configurable.
Auto-dim lighting control; screen brightness decreases automatically after the environment gets dark for 3 seconds.
Auto scan function available, each channel can turn on or off auto scan function and adjust the scan time from 5 to 60 seconds.
Rear view parking lines can be configured.

LCD Dimension	7"
Resolution	1024x 3 (RGB) x600
Contrast	700:1
Brightness	650cd/m²
Viewing Angle	U:85 / D:85, R/L:85
Aspect Ratio	16:9
Channel	4 channels
Operating Frequency	2408MHz ~ 2478MHz(ISM band)
Receiving Sensitivity	-78dBm
Transmission Power	FCC≤26dBm CE≤20dBm MIC≤10dBm
Decompression Form	H.264
Modulation	FHSS
Delay	130ms
Transmission Distance	FCC≤300 M CE≤200 M MIC≤60 M
System Format	PAL / NTSC
Power Supply	DC 10-32V
Power Consumption	Max.10W
Loudspeaker	1.5W/8Ω
Operating Temp. & Humidity	-20~+70ºC,RH90%MAX
Storage Temp. & Humidity	-30~+80ºC,RH90%MAX

What are the benefits of STONKAM® Waterproof 7 inch Digital Wireless Vehicle Monitor?

Easy Installation + Instant Pairing = Save more money and efficiency

After being paired for the first time, the wireless monitor and wireless camera start to function simply by connecting them to power supply of the vehicle.

wireless monitor and wireless camera

Strong anti-interference, Stable connection

Operating frequency: 2408MHz ~ 2478MHz

STONKAM® wireless camera system adopts the FHSS technology to guarantee the privacy and anti-interference of connection.

wireless camera system

Open transmission distance up to 984ft (300m)

wireless camera system

IP66 rated waterproof, normal working in rainy days

IP66 Waterproof 7 inch wireless monitor can work continuously and stably under the condition of getting wet or soaking.With IP69K rating, our metal constructed cameras are durable and especially suits commercial and industrial vehicles.

IP66 Waterproof 7 inch wireless monitor

Support multiple display modes, such as quad-view mode, split-view mode, single view mode.

The channels for the quad-view and split-view can be set flexibly.

IP66 Waterproof 7 inch wireless monitor

Touch screen optional

IP66 Waterproof 7 inch wireless monitor

Multiple Application Scenarios

With top grade high quality, STONKAM® HD Digital Wireless Vehicle Monitor can be applied to various vehicles, such as forklift, crane, harvester, etc.


Harvester	Excavator

Farm	Forklift

Forklift	Planter

STONKAM® bedient ausschließlich Unternehmen. Bitte stellen Sie sicher, dass die E-Mail-Adresse des Unternehmens sowie die Angaben zum Land/der Region korrekt sind. Wir werden Ihnen so schnell wie möglich antworten!

Merkmale

Support 4CH wireless camera and wireless transmitter.

Waterproof; with built-in antenna.

Support multiple display modes, such as quad-view mode, split-view mode, single view mode, and the channels for the quad-view and split-view can be set flexibly.

Supports both manual and automatic pairing.

Supporting 1080P/720P camera input.

Touch screen optional.

Support 5 trigger input-wires, includes 4 channel single view trigger display and 1 channel split view trigger display, and the split view image can be set flexibly. In addition, the trigger for time to return the main display and triggering priority of 5 trigger input-wires can be configurable.

Auto-dim lighting control; screen brightness decreases automatically after the environment gets dark for 3 seconds.

Auto scan function available, each channel can turn on or off auto scan function and adjust the scan time from 5 to 60 seconds.

Rear view parking lines can be configured.

LCD Dimension

7"

Resolution

1024x 3 (RGB) x600

Contrast

700:1

Brightness

650cd/m²

Viewing Angle

U:85 / D:85, R/L:85

Aspect Ratio

16:9

Channel

4 channels

Operating Frequency

2408MHz ~ 2478MHz(ISM band)

Receiving Sensitivity

-78dBm

Transmission Power

FCC≤26dBm

CE≤20dBm

MIC≤10dBm

Decompression Form

H.264

Modulation

FHSS

Delay

130ms

Transmission Distance

FCC≤300 M

CE≤200 M

MIC≤60 M

System Format

PAL / NTSC

Power Supply

DC 10-32V

Power Consumption

Max.10W

Loudspeaker

1.5W/8Ω

Operating Temp. & Humidity

-20~+70ºC,RH90%MAX

Storage Temp. & Humidity

-30~+80ºC,RH90%MAX

What are the benefits of STONKAM® Waterproof 7 inch Digital Wireless Vehicle Monitor?

Easy Installation + Instant Pairing = Save more money and efficiency

After being paired for the first time, the wireless monitor and wireless camera start to function simply by connecting them to power supply of the vehicle.

Strong anti-interference, Stable connection

Operating frequency: 2408MHz ~ 2478MHz

STONKAM® wireless camera system adopts the FHSS technology to guarantee the privacy and anti-interference of connection.

Open transmission distance up to 984ft (300m)

IP66 rated waterproof, normal working in rainy days

IP66 Waterproof 7 inch wireless monitor can work continuously and stably under the condition of getting wet or soaking.With IP69K rating, our metal constructed cameras are durable and especially suits commercial and industrial vehicles.

Support multiple display modes, such as quad-view mode, split-view mode, single view mode.

The channels for the quad-view and split-view can be set flexibly.

Touch screen optional

Multiple Application Scenarios

With top grade high quality, STONKAM® HD Digital Wireless Vehicle Monitor can be applied to various vehicles, such as forklift, crane, harvester, etc.

Harvester

Excavator

Forklift

Forklift

Planter
